Manufacturer Direct Selling Saponin Color Sorter Hons Sorting Machine

Basic Information
Place of Origin: Anhui,China
Brand Name: Hons
Certification: ISO9001,SGS,CE
Model Number: S8
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Wooden case
Delivery Time: 10-15 Work Days
Payment Terms: L/C, T/T
Supply Ability: 100sets per month
Detail Information
Name: 6SXM-504(CCD) Capacity(T/h): 7.0~11.0
Voltage(V): AC220V/50Hz Power(Kw): ≤4.6
Weight(Kg): 1800(±5%) Dimension(L*W*H Mm): 3152*1595*2040
Color: White Channels: 8
Application: Sorting Product Name: Raisins Color Sorter

Product Description





Manufacturer Direct Selling Saponin Color Sorter Hons Sorting Machine

Manufacturer Direct Selling Saponin Color Sorter Hons Sorting Machine 0

Features:
1. Raw Material are put into the machine from its feeding hopper on the top.
2. Vibrated by vibration device and sliding along material chute into the zone of observation in sorting chamber through sensor and background plate .
3. Under the effect of light source, CCD sensor receives compound light from materials being sorted.
4. According to the light intensity and color changes, make the system produce output signal and drive solenoid valve to work ,ejecting the discolor grain to defect chamber and good materials continue to fall into the finished goods chamber.



No. Item Content
1 CCD Sensor 54 Million Pixel
2 Operation Systerm Windows 7
3 Solenoid Valve 60 ~ 100 Million Times Of Service Life
4 Production Capacity 20% ~ 30% more than other brand
5 Fuction Unlimited Mode For Various Material





Technical Parameter

Model S1 S2 S3 S4 S5 S6 S7 S8 S10 S12
Capacity(t/h) 0.8~2.0 1.2~2.5 1.5~3 3~6 4~7 5~8 6~10 7~11 7~15 10~18

Voltage

(V)

AC220V 50/60Hz AC220V 50/60Hz AC220V 50/60Hz AC220V 50/60Hz AC220V 50/60Hz AC220V 50/60Hz AC220V 50/60Hz AC220V 50/60Hz AC220V 50/60Hz AC220V 50/60Hz
Power(KW) ﹤1.5 ﹤2 ﹤2.4 ﹤2.6 ﹤3.0 ﹤3.6 ﹤4.0 ﹤4.6 ﹤5.5 ﹤7.0

Air pressure

(Mpa)

0.6-0.8 0.6-0.8 0.6-0.8 0.6-0.8 0.6-0.8 0.6-0.8 0.6-0.8 0.6-0.8 0.6-0.8 0.6-0.8

Dimension

(mm)

910*
1620*1550
1220*
1615*1550
1628*
1595*2040
1870*
1595*2040
2210*
1595*2040
2528*
1595*2040
2836*
1595*2040
3152*
1595*2040
3910*
1595*2040
4594*
1595*2100
Weight (Kg) 350 500 800 1000 1250 1400 1600 1800 2250 2700
















High Capacity RGB Camera CCD Color Sorter Machine With Voltage 220V 6SXM-315















Sorting result

Raw Material

Manufacturer Direct Selling Saponin Color Sorter Hons Sorting Machine 2

Accept

Manufacturer Direct Selling Saponin Color Sorter Hons Sorting Machine 3

Rejection

Manufacturer Direct Selling Saponin Color Sorter Hons Sorting Machine 4













Company view

Manufacturer Direct Selling Saponin Color Sorter Hons Sorting Machine 5


Workshop view

Manufacturer Direct Selling Saponin Color Sorter Hons Sorting Machine 6



Customers site

Manufacturer Direct Selling Saponin Color Sorter Hons Sorting Machine 7

Exhibition &Team

Manufacturer Direct Selling Saponin Color Sorter Hons Sorting Machine 8



































Packaging & shipping
Delivery Detail:
Shipped in 15 days after payment
Packaging: Plywood case






Our Service
1. The company persists in the “Service is Available at Any Time” guidelines, advocates all staffs to pay close attention to the customer demands at any time, and endeavors to provide the solutions for the domestic and overseas customers.
2. At present, the company has more than 30 after-sales service staffs, who offer the service extending to the prefecture level, contact the customers directly, provide the timely, rapid and considerate service for the customers, and realize the door-to-door service within 72 hours.
3. Carry out one-year free maintenance and care of the complete machine for the customers, provide the professional training and technical guidance timely to solve the worries of the customers, and reflect the service mode of fast response, imely maintenance and tracking coordination fully.
