| Place of Origin: | Anhui,China |
|---|---|
| Brand Name: | Hons |
| Certification: | ISO9001/SGS/CE |
| Model Number: | S4 |
| Minimum Order Quantity: | Negotiable |
| Price: | $10000-$14500 |
| Packaging Details: | Wooden case |
| Delivery Time: | 10-15 Work Days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 100sets per month |
| Product Name: | Seafood Color Sorter | Voltage(V): | AC220V/50Hz |
|---|---|---|---|
| Name: | 6SXM-252(CCD) | Capacity(T/h): | 3.0~6.0 |
| Power(Kw): | ≤2.6 | Weight(Kg): | 1000(±5%) |
| Dimension(L*W*H Mm): | 1880*1595*2040 | Color: | White |
| Channels: | 4 | Application: | Sorting |
| High Light: | Red lentil sorter machine,seafood Automatic color sorter,4 channels seafood color sorter |
||
Technical characteristic
1. Automatically collecting hyper space data such as color,shape,size,and defect to cachieve accurate acquisition of raw materila features
2. The world's leading full-color linear array scanning technology and DPS+FPGA parallel multi-line pipeline processing technologgy to solve the problem, use multiple intelligent algorithm, high accuracy sorting, special for small speck, light yellow, chalky, discolor.(5400 pixels)
3. The self-developed magnetically controlled high-frequency solenoid valve achieves flexible contact between devices and has a service life of more than 6 to 10 billion times. Meanwhile, intelligent repair technology reduces maintenance costs and extends liofetime of valve.
4. The advances digital non-polar intelligent dimming technology can automatically match the best brightness according to the material selection requirements and the changes of enviroment to guarantee the sorting perfoermance.
5. Intelligent operation platform with storage of 100 sorting modes can achieve multiple functions of one machine, user-friendly control and easy to operate.
6. The patented intelligent dust-extraction system can rapidly remove light objects and dusts adhered to the materials, for which ensuring the sorting accuracy and improving machine efficient.
Technical Parameter
| Model | S1 | S2 | S3 | S4 | S5 | S6 | S7 | S8 | S10 | S12 |
| Capacity(t/h) | 0.8~2.0 | 1.2~2.5 | 1.5~3 | 3~6 | 4~7 | 5~8 | 6~10 | 7~11 | 7~15 | 10~18 |
|
Voltage (V) |
AC220V 50/60Hz | AC220V 50/60Hz | AC220V 50/60Hz | AC220V 50/60Hz | AC220V 50/60Hz | AC220V 50/60Hz | AC220V 50/60Hz | AC220V 50/60Hz | AC220V 50/60Hz | AC220V 50/60Hz |
| Power(KW) | ﹤1.5 | ﹤2 | ﹤2.4 | ﹤2.6 | ﹤3.0 | ﹤3.6 | ﹤4.0 | ﹤4.6 | ﹤5.5 | ﹤7.0 |
|
Air pressure (Mpa) |
0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 |
|
Dimension (mm) |
910* 1620*1550 |
1220* 1615*1550 |
1628* 1595*2040 |
1870* 1595*2040 |
2210* 1595*2040 |
2528* 1595*2040 |
2836* 1595*2040 |
3152* 1595*2040 |
3910* 1595*2040 |
4594* 1595*2100 |
| Weight (Kg) | 350 | 500 | 800 | 1000 | 1250 | 1400 | 1600 | 1800 | 2250 | 2700 |
Sorting performance
FAQ
1. How many days for production?
In general,within8-12workers days after getting deposit payment.
2.Are you a trading company or a factory,will it be cheaper to buy from your side?
More than 15 years of professional manufacturing experience, more than 10years exporting experience overseas,more reliable quality,more timely service.
The same quality, more favorable price.
3.Do you provide product installation,training and after-sales service?
Most products can be installed and trained through online video and text mode.If special products need to be installed on site,we will arrange technicians to install and debug on site.
4.We are small buyer , can we buy your products locally , do you have local agents?
If you need to buy locally ,please tell us your region name,we can recommend the most suitable local dealer for you.
About us
ANHUI HONGSHI OPTOELECTRONIC HIGH-TECH Co., Ltd., which belongs to Anhui Hongshi Group, is a multi-industry and integrated enterprise related to optical and electronic products development, machinery processing, auto sales, spare parts sales, decoration project and cultural media.
Now our products are sold all over China and exported to more than 10 countries like Russia, India, Pakistan, Thailand, Brazil, Peru, Sri Lanka, Gambia, Bhutan. Ecuador, etc.
