Intelligent Optical Rice/Beans Color Separator Machine Processing Line

Basic Information
Place of Origin: Anhui,China
Brand Name: Hons
Certification: CE/SGS
Model Number: 6SXM-63(CCD)A
Minimum Order Quantity: 1 pc
Price: $6500-$8500
Packaging Details: Wooden case
Delivery Time: 5-8 working days
Payment Terms: D/A, D/P, T/T, L/C
Supply Ability: 500sets/month
Detail Information
Product Name: Rice Color Resorter Input Voltage: AC220V/50HZ
Capacity(T/H): 0.6-1T/H Prouct Size: L 910mm * W 1620mm * H 1550mm
Power(KW): ≤1.5 Product Weight: 350kgs
Warranty: 1 Year Channel: 63 Channels
CCD Sensor: Toshiba Feature: High Quality FPGA Processing

Product Description

Intelligent Optical Rice/Beans Color Separator Machine Processing Line



Sorting Materials:



1. Beans: soybeans, mung beans, red beans, coffee beans,chickpea,red lentils

2. Rice: white rice, parbouled rice,black rice, yellow rice, brown rice, barley rice
3. Nuts: peanuts, ground nut,cashew nut, walnut meat,pine

4. Wheat: Buckwheat,Quinoa,Qatmeal.
5. Vegetable: dry onion,daylily,back fungus,sea vegetables
6. Food: vegetable seeds, cumin seeds,prickly ash seeds,dried shrimps,small shrimp

7. Industrial: plastic, broken glass,quaze,ore,scrap metal,slag,salt,refractory



CCD color sorter machine parameters



Name S1 S3 S5 S7
Model 6SXM-63 6SXM-189 6SXM-315 6SXM-441
Capacity(Kg/H) 800Kg-1000Kg 2000Kg-3000Kg 3000Kg-4000Kg 5000Kg-6000Kg
Voltage(V) AC220V/50HZ AC220V/50HZ AC220V/50HZ AC220V/50HZ
POWER(KW) <1.5 <2.4 <3.0 <4.0
Weight(KG) 350Kg 800Kg 1250Kg 1600Kg
Dimension(L*W*H/MM) 910*1620*1550 1628*1595*2040 2210*1595*2010 2836*1595*1850
Air Consumption 0.9 m³/min 1.8m³/min
1.8 m³/min

3 m³/min
Air pressure 0.6-0.8mpa 0.6-0.8mpa 0.6-0.8mpa 0.6-0.8mpa
Air compressor power 4kw 7.5Kw 11kw*2 15kw*2
Air tank   600L 1000L 1000L
Cooling Model wind cooling wind cooling wind cooling wind cooling
Mini Resolution( mm²) 0.03 0.03 0.03 0.03



CCD color sorter machine strength



Cloud braininterconnection



1Remote interconnection: Easy connection of touch screen and mobile devices, intelligent control to enjoy the wisdom of life.

2. Remote diagnosis: Start-up self checking of system can achieve real-time monitoring of machine components, automatically judgement and troubleshooting to ensure the normal operation of color sorter.
3. Remote upgrade: Intelligent self checking system realizes one-key system upgrade and provides the best operation experience
4. Remote training: A efficient and convenient real-time interactive training system developed independently, creating non-distance service for users.



Cloud brain vision

Intelligent image acquisition system

Automatic collection of hyperspatial data such as color, shape, size and defect to achieve accurate acquisition of raw material characteristics.



The international leading full-color high-speed three-series scanning CCD sensor (54 million pixels * 3), perfect processing of small defect materials, the smallest scanning and recognition area can reach 0.2 mm * 0.2 mm = 0.04 mm ²; At the same time, the ability of multithreading to handle "color + shape".



Rice Mill CCD Color Sorter Machine SGS Mini 1.0 T/H 0




Sorting Perofrmance



Rice Mill CCD Color Sorter Machine SGS Mini 1.0 T/H 1

Rice Mill CCD Color Sorter Machine SGS Mini 1.0 T/H 2
Rice Mill CCD Color Sorter Machine SGS Mini 1.0 T/H 3

Intelligent Optical Rice/Beans Color Separator Machine Processing Line 4





FAQ

1. How to use the machine?
We will supply customer the installation catalog or video online.

We will ask our engineer to teach you, how to use when he go to your country to debug the machine.

2. How about the sample machines for testing?
Sample sending for testing is welcomed.

Or you send these three photos, the raw material, good material (which is you want) ,bad material (which is you want to discard).we send our video to you.

3. How about the guarantee period?
One year.



Why choose us

1. The leading photoelectric detection and classification equipment supplier.

2. W supply optic detection and classification equipment as rice color sorting machine, grain CCD color sorter machine,grain color sortingmachine,grain color sorting machine, tea color sorting machine,belt color sorting machine ect,and also offfer the effective fast solution for relative industry.

3. Hons+ brand series product have been popular both in domastic and oversea market many years, we have exported over than 20 countries with high praise from customers.

Add.: No.2 Yan'an Road, Baohe Industrial Area, Hefei, Anhui Province, China



 Rice Mill CCD Color Sorter Machine SGS Mini 1.0 T/H 4

Rice Mill CCD Color Sorter Machine SGS Mini 1.0 T/H 5
