CCD Coffee Beans Colour Sorter Machine 6 Chutes Multiple Function

Basic Information
Place of Origin: China
Brand Name: Hons+
Certification: ISO/SGS/CE
Model Number: S6
Minimum Order Quantity: 1 set
Price: $13500-$19000
Packaging Details: Wooden case
Delivery Time: 5-8 worker days
Payment Terms: L/C, D/P, D/A, T/T
Supply Ability: 500sets/month
Detail Information
Power(Kw): 3.6 Dimension(L*W*Hmm): 2528*1595*2040
Capacity(T/h): 3.0t-4.0t Voltage(V): AC220V/50Hz
Weight(Kg): 1400kg Applicable Material: Peanut/Rice/grain
Pixels: 54 Million Feature: High Sensitivity
Product Name: CCD Color Sorter
High Light:

6 Chutes Colour Sorter Machine


Multiple Function Colour Sorter Machine


CCD Color Sorter 6 Chutes

Product Description

6 Chutes CCD Intelligent Multiple Function Coffee Beans Colour Sorter Machine

Main Features

1. The color sorter adopts 5400+ high-performance CCD sensor with a resolution of 0.1mm.

2. The sorting machine adopts high-quality industrial special lenses specially designed and manufactured for color sorting.
3. High-speed FPGA technology signal processor, fast detection speed and high recognition rate.
4. The whole machine adopts intelligent closed-loop control.
5. The parameter setting is simple and the operation is simple.
6. Adopt high-speed air volume value to ensure fast response, low power consumption and long service life.
7. The sorting machine adopts intelligent temperature and air pressure control technology to ensure that the whole machine is in the best running state.
8. Automatic fault alarm, modular structure, easy maintenance.


Technology parameters

S1 S2 S5 S6
Model 6SXM-63 6SXM-126 6SXM-315 6SXM-378
Capacity(Kg/H) 300Kg-400Kg 300Kg-800Kg 1200Kg-1600Kg 1800Kg-3000Kg
Voltage(V) AC220V/50HZ AC220V/50HZ AC220V/50HZ AC220V/50HZ
POWER(KW) <1.5 <2.0 <3.0 <3.6
Weight(KG) 350Kg 500Kg 1250Kg 1400Kg
Dimension(L*W*H/MM) 910*1620*1550 1220*1620*1550 2210*1595*2040 2528*1595*2040
Air Consumption 0.9 m³/min 1.8m³/min
1.8 m³/min

3 m³/min
Air pressure 0.6-0.8mpa 0.6-0.8mpa 0.6-0.8mpa 0.6-0.8mpa
Air compressor power 4kw 5.5Kw 11kw*2 15kw*2
Air tank   300L 1000L 1000L
Cooling Model wind cooling wind cooling wind cooling wind cooling
Mini Resolution( mm²) 0.03 0.03 0.03 0.03


CCD Coffee Beans Colour Sorter Machine 6 Chutes Multiple Function 0


Sorting materials


Beans: soybeans/mungbeans/red beans/broad beans

Nuts: peanuts/cashew nuts/walnut meat/pine nuts

Rice: white/black/red/yellow/barley rice

Wheat: buckwheat/quinoa/oatmeal

Corn: corn particles/white corn/ ellowcorn/black corn

Dry food: dry onion/ raisins/dried chilli

Seeds: sunflower seeds/ rice seeds/ vegetable seeds


Sorting performance

CCD Coffee Beans Colour Sorter Machine 6 Chutes Multiple Function 1

 CCD Coffee Beans Colour Sorter Machine 6 Chutes Multiple Function 2

CCD Coffee Beans Colour Sorter Machine 6 Chutes Multiple Function 3



1. How to use the machine?
We will supply customer the installation catalog or video online.

2. How about the sample machines for testing?
Sample sending for testing is welcomed.Or you send these three photos, the raw material, good material (which is you want) ,bad material (which is you want to discard).we send our video to you.

3. How about the guarantee period?
One year.

4. Will you accept L/C as payment?
L/C, T/T is OK .


Why Choose Hons+:

1. Over 10 years experience, specializing in color sorter machines.
2. After-sales service guarantee: We have a professional after-sales service team and one-to-one customer service to help customers install and debug.
3. We have gas stations in Southeast Asia, re-seller cooperation in more than 50 countries.
4. Quality assurance of raw materials: The raw materials we buy are certified qualified products.
5. Quality assurance process: We have authorized CE & ISO quality management system, and every production process is subject to strict standards.
6. System testing: Our technical engineers check the product performance, even every part is subject to strict aging test to ensure that the factory products fully meet customer needs.
7. Guarantee: We have a professional packaging operation team and independent export qualifications to ensure that the products reach customers safely and stably.

 CCD Coffee Beans Colour Sorter Machine 6 Chutes Multiple Function 4

CCD Coffee Beans Colour Sorter Machine 6 Chutes Multiple Function 5
